易于維護
只需更換LED燈條即可輕松進行(xing)維護
自由切割技術
M-Shine側發光(guang)透明LED除了(le)標準尺(chi)寸外，還可(ke)以通過自(zi)由切(qie)割技術(shu)定(ding)制成(cheng)不同的形(xing)狀。
超高透明度
側發(fa)光(guang)設計，透光(guang)率高(gao)達87%，亮度(du)高(gao)達5500nits，帶來(lai)極致視覺(jue)享受(shou)
超廣視角
160°超廣視角，輕松捕捉完美顯(xian)示效果
單面PC/雙面PC/無PC蓋設計可選
多種PC蓋設計方案(an)選擇(ze)，滿足不同(tong)需求(qiu)
Crystal Series - Free cutting side emitting transparent LED Pixel Pitch(mm) 3.9*7.8mm 7.8*7.8mm 10.4*10.4mm Pixel Density(dots/㎡) 32768 16384 9216 Brightness(cd/㎡) 5000cd 1200cd 5000cd 1200cd 5000cd 1200cd Cabinet Size(mm) 1000*500 or customized, can be free cutting into any shape Cabinet Resolution(dots) 256*64 128*64 96*48 Panel Maximum Power(W) 500W 400W 500W 400W 500W 400W Panel Average Power(W) 300W 120W 300W 120W 300W 120W Max.Power Consumption(W/㎡) 1000w 800W 1000w 800W 1000w 800W Transparency Rate 87% 85% 87% Viewing Distance(m) 4m 8m 10m Driving Method 1/4 scan 1/4 scan 1/2 scan Pixel Composition 1R1G1B Operating Input Voltage(V) 5V LED Driving Method Constant Current Gray Scale 16 bits Brightness Adjustment 256 Brightness Levels Refresh Rate 3840Hz Refresh Frame Frenquncy 60HZ Maintenance Way Rear Service Ingress Protection IP31 Weight(kg/㎡) 16KG Continuous Use Time >72h Life Span 100,000h MTBF >10,000h Blind Spot Rate <0.01% Operating Temperature -20℃～+50℃(Below -20 degrees could be customized) Operating Humidity Indoor 10%～60%
透明屏
首頁透明屏
Crystal水晶系列
自由剪裁側發光LED透明屏
尺(chi)寸：1000x500mm/ 1000x1000mm / 自由剪(jian)裁尺(chi)寸
像素間距(ju)：P3.91-7.81/ P7.81-7.81/ P5.2-10.42
通透率可達87%
輕巧纖薄
亮度可達5500nits/㎡
應用領域：購(gou)物中(zhong)心(xin)、連(lian)鎖店、舞(wu)臺裝(zhuang)飾、廣(guang)告媒體、藝術中(zhong)心(xin)、展廳等
